Research Grade Inverted Metallographi c Microscope.

1. Optical system: Infinity optical system. 2. Total magnification: 100X-1000X. 3. Eyepiece: Wide field plan eyepiece WF10X (Φ22mm). 4. Objective: Infinite long working distance plan objective PLL10X/PLL20X/PLL50X/PLL100X (dry). 5. Observation head: Hinged, inclined 45°, trinocular head. 6. Nosepiece: Five-hole (inward-facing ball positioning). 7. Stage: Mechanical large - area movable stage: 242mm×200mm, travel range: 30mm×30mm. 8. Illumination system: Halogen lamp with adjustable brightness.
